Cell parameters
|
||
|
Cell type
|
LFP
|
|
|
Cell specification
|
3.2V/280Ah
|
|
|
Maximum magnification
|
0.5C
|
|
|
cycle life
|
6000 times@25℃，0.5P/0.5P
|
|
|
Operating temperature
|
Charging temperature 0-55，discharging temperature -20-55℃
|
|
|
Battery module parameters
|
||
|
Combination
|
16S
|
|
|
Rated Capacity
|
280Ah
|
|
|
Rated voltage
|
51.2V
|
|
|
Rated energy
|
14.336KWh
|
|
|
Maximum magnification
|
0.5C
|
|
|
Battery Cluster Parameters
|
||
|
Number of Packs per cluster
|
14
|
|
|
Rated Capacity
|
280Ah
|
|
|
Rated voltage
|
716.8V
|
|
|
Rated energy
|
200.704KWh
|
|
|
Maximum magnification
|
0.5C
|
|
|
Battery compartment system parameters
|
||
|
Rated energy
|
2007.4KWh
|
|
|
Rated voltage
|
716.8V
|
|
|
Maximum magnification
|
0.5C
|
|
|
cooling method
|
air cooled
|
|
|
maintenance method
|
walk in
|
|
|
degree of protection
|
IP54
|
|
|
System communication interface
|
CAN/RS485/Ethernet
|
|
|
System communication interface
|
Modbus-RTU/Modbus-TCP/IEC 61850
|
|
|
Dimensions（L*W*H mm）
|
12192*2438*2896
|
|
Huijue Group was founded in 2002, is in the field of energy storage system in the leading technology innovation company, toprovide customers with the optimal energy storage system solutions and safe and efficient storage full range of products, covering household energy storage system, industrial and commercial energy storage system and site energy storage system.Huijue Group headquarters is located in Shanghai free trade zone lingang new area, has six wholly owned subsidiary, in Jiangsu Haian and Shanghai Fengpu production base and research and development center, the total area of 100000 square meters, more than one thousand employees, has four professional integrated production line, with senior technical team and efficient supply chain system, capacity and performance ability fully guarantee. Sales and service outlets are all over cities across the country, and the products are exported to many countries and regions around the world. Smart energy solutions have been widely used in government, transportation, education, operators and other industries. Over the years, won the “high-tech enterprise” and “innovative enterprise” and other honorary certification.
